Behringer Xenyx 802S
Behringer Xenyx 802S
Behringer Xenyx 802S

Behringer Xenyx 802S

Brand: Behringer Categories: ,

$141.01

0 reviews

Designed for streaming, podcasting, and recording, the Behringer XENYX 802S is a 5-input mixer with an integrated 2×2 USB audio interface that offers clear and natural sound in a compact and portable format.

Description

ย Premium Analog 8-Input Mixer with USB Streaming

Designed for streaming, podcasting, and recording, the Behringer XENYX 802S is a 5-input mixer with an integrated 2×2 USB audio interface that offers clear and natural sound in a compact and portable format. The mixer features two high-quality XENYX mic preamps with phantom power for working with high-end condenser microphones. Additionally, there are three sets of 1/4″ stereo line inputs, stereo RCA inputs and outputs, and a 1/4″ FX send as well as a 1/4″ headphone output.

The XENYX 802S is easy to set up and operate with all connections and controls easily reachable from the top of the unit. The two mic channel inputs and stereo inputs 3/4 & 5/6 feature 3-band British-style EQ and panning knobs, while channel 7/8 offers a simple level control. The stereo USB audio interface allows you to record your mix directly to a computer and then play it back.

FEATURES
  • Ultralow-noise analog mixer for streaming, podcasting, and recording
  • 2 Award-winning XENYX microphone preamps for warm and musical sound
  • Stereo USB audio interface to connect to your computer or mobile device
  • Direct mixing of PC/gaming sounds into the streaming output
  • Analog mixing and equalization for pure sound
  • Versatile sub mixer for network-enabled audio devices
  • Stereo channel 7/8 automatically switches between TRS input and USB playback
  • 3-band EQs for warm and musical sound
  • FX send control per channel for external FX processor or monitoring mix
  • High-quality monitoring, phones and streaming outputs
  • Stereo RCA inputs assignable to main mix or monitor/phones outputs

SPECIFICATIONS

Number of Analog Input Channels
8 (2 Mono / 6 Stereo)
Number of Mic Preamps
2
Analog Output Channels
1x Stereo Master Output
1x Stereo Tape/Record Output
1x Stereo Headphone Output
Mix Routing
Stereo Main Mix
EQ
3-Band EQ
Built-In Effects
No
USB I/O
1x USB-B
Wireless
No
Rack Mountable
No
Mixer
Number of Analog Input Channels
8 (2 Mono / 6 Stereo)
Number of Mic Preamps
2
Analog Output Channels
1x Stereo Master Output
1x Stereo Tape/Record Output
1x Stereo Headphone Output
Mix Routing
Stereo Main Mix
Faders & Level Adjustment
5x Channel Knob
1x Master Knob
Meters
2x 4-Segment LED
Signal Processing
Gain/Trim Range
XLR Mic Input:
+10 dB to +60 dB
1/4″ Line Input:
-10 dB to +40 dB
Dynamic Processing
No
EQ
3-Band EQ
EQ Parameters
Low: ยฑ15 dB at 80 Hz
Mid: ยฑ15 dB at 2.5 kHz
High: ยฑ15 dB at 12 kHz
Graphic EQ
No
Solo/Mute
No
Built-In Effects
No
Digital Audio
Sample Rates
48 kHz
Bit Depth
16-Bit
Performance
Frequency Response
Line InputAnalog :
20 Hz to 200 kHz
Mic Input:
10 Hz to 150 kHz (+10 dB Gain)
20 Hz to 70 kHz (+60 dB Gain)
Max Input Level
XLR Mic Input:
+12 dBu at +10 dB Gain
1/4″ TRS Line Input:
+21 dBu at Unity Gain
RCA Line Input:
+10 dBu
I/O Impedance
XLR Mic Input:
2 Kilohms (Balanced)
1/4″ TRS Line Input:
22 Kilohms (Balanced)
10 Kilohms (Unbalanced)
Stereo RCA Input:
10 Kilohms (Unbalanced)
1/4″ TRS FX/Main/Monitor Output:
120 Ohms (Balanced)
1/4″ TRS Headphone Output:
23 Ohms
Stereo RCA Line Output:
1 Kilohm (Unbalanced)
Noise Floor
-109 dBu A-Weighted (Master Level at -โˆž, Channel Levels at -โˆž)
THD+N
Mic Input to Analog Output:
0.005% at +10 dB Gain (1 kHz)
Connectivity
Analog Inputs
2x XLR TRS Balanced Mic Input
2x 1/4″ TRS Balanced/Unbalanced Line Input
6x 1/4″ TRS Balanced/Unbalanced Stereo Line Input (3 Stereo Pair)
1x Stereo RCA Coaxial Unbalanced Line Input (1 Stereo Pair)
Analog Outputs
2x 1/4″ TRS Balanced/Unbalanced Main Output
2x 1/4″ TRS Balanced/Unbalanced Monitor Output
1x 1/4″ TRS Balanced/Unbalanced FX Send
1x Stereo RCA Coaxial Unbalanced Stereo Line Output (1 Stereo Pair)
1x 1/4″ TRS Unbalanced Headphone Output
Phantom Power
+48 V
Digital I/O
No
MIDI I/O
No
USB I/O
1x USB-B
USB I/O Capacity
2x Input / 2x Output
Wireless
No
Compatibility
OS Compatibility
Windows / macOS
OS Compatibility
Windows
macOS
Power
Input Power
100 to 240 VAC, 50 / 60 Hz
DC Input Power
18 VDC at 1A
Physical
Rack Mountable
No
Dimensions
7.4 x 1.9 x 8.7″ / 188 x 48.3 x 221ย mm
Weight
3.5ย lb / 1.6ย kg
Packaging Info
Package Weight
3.61 lb
Box Dimensions (LxWxH)
12.7 x 10.9 x 3.7″
